| Kondisi | Used |
|---|---|
| Lokasi | DKI JAKARTA |
Dijual atas Rough Terrain Crane :
- Merek Tadano
- Model TR250M-6 (Crevo 250)
- Kapasitas 25 Ton
- Ex Import & Built Up
- Masuk Indonesia tahun 2017 (sesuai Document Import)
- Pembuatan tahun 2013
- Kondisi siap kerja
- Harga Rp. 1,875 Milyar (Belum termasuk PPN)
Untuk informasi lebih lanjut dapat menghubungi Bp. MANAN di 0813-85189222 & Whatsapp di 0812-35189222 atau 021-8510550
Rp. 1,875 M
Technical Specifications
| Min Height @ Max Raise Angle | 9500.6 mm |
|---|---|
| Max Height @ Max Raise Angle - No Jib | 30501.3 mm |
| Max Elevating Angle | 83 degrees |
| Number Of Sections | 4 |
| Swing Speed | 2.6 rpm |
| Transport Length | 11131.3 mm |
| Transport Width | 2621.3 mm |
| Transport Height | 3410.7 mm |
| Wheelbase | 3500.1 mm |
| Width W/ Outriggers Extended | 6300.2 mm |
| Carrier/Base Length | 7350002.1 mm |
| Upper Structure Tail Swing Radius | 3102.9 mm |
| Number Of Cylinders | 6 |
| Engine Make | Mitsubishi |
| Engine Model | 6D16 |
| Gross Power | 183.9 kw |
| Power Measured @ | 2800 rpm |
| Max Torque | 706.1 Nm |
| Torque Measured @ | 1400 rpm |
| Displacement | 7.5 L |
| Aspiration | Water-cooled |
| Operating Weight | 26495 kg |
| Fuel Capacity | 300.2 L |
| Hydraulic System Fluid Capacity | 380.1 L |
| Operating Voltage | 24 V |
| Tire Size | 385/95R25 |
| Transmission Type | Powershift |
| Number Of Forward Gears | 4 |
| Number Of Reverse Gears | 1 |
| Max Speed - Forward | 49.1 km/h |
