Component Alat Berat
Parts Book / Catalog / Manual Caterpillar 320C
SKU: 1210410001
Last Update: 2022-01-17
| Kondisi | Used |
|---|---|
| Serial Number | AMC1-Up & ANB1-xx |
| Lokasi | DKI JAKARTA |
Jual Parts Manual untuk :
- Merek Caterpillar
- Type Excavator
- Model 320C & 320C L
- Serial Number Machine AMC1-Up & ANB1-Up
- Engine Number 7JK1-Up
- Harga Rp. 325.000,-
Juga tersedia untuk banyak Merek, Type dan Model atas Alat Berat. Kunjungi Web kami di http://www.tractortruck.com atau 082365693888
Rp. 325 Jt
Technical Specifications
| Shipping Length Of Unit | 10043.2 mm |
|---|---|
| Shipping Height Of Unit | 3011.4 mm |
| Max Cutting Height | 10850.9 mm |
| Max Loading Height | 7690.1 mm |
| Max Reach Along Ground | 9351.3 mm |
| Max Vertical Wall Digging Depth | 3282.7 mm |
| Max Digging Depth | 4160.5 mm |
| Boom/Stick Option (Hex) 1 | boom w/ stick R1.9C 1900mm |
| Shipping Length Of Unit | 9710.9 mm |
| Max Cutting Height | 10250.4 mm |
| Shipping Height Of Unit | 3011.4 mm |
| Max Loading Height | 8482.6 mm |
| Max Reach Along Ground | 9820.7 mm |
| Max Vertical Wall Digging Depth | 3761.2 mm |
| Max Digging Depth | 4602.5 mm |
| Boom/Stick Option (Hex) 2 | boom w/ stick R2.5B 2500mm |
| Shipping Length Of Unit | 9692.6 mm |
| Max Cutting Height | 11622 mm |
| Max Loading Height | 8900.2 mm |
| Shipping Height Of Unit | 3011.4 mm |
| Max Reach Along Ground | 10241.3 mm |
| Max Vertical Wall Digging Depth | 4160.5 mm |
| Max Digging Depth | 5020.1 mm |
| Boom/Stick Option (Hex) 3 | boom w/ stick R2.9B 2900mm |
| Shipping Length Of Unit | 9372.6 mm |
| Shipping Height Of Unit | 4059.9 mm |
| Max Cutting Height | 12390.1 mm |
| Max Loading Height | 9640.8 mm |
| Max Reach Along Ground | 11140.4 mm |
| Max Digging Depth | 5961.9 mm |
| Boom/Stick Option (Hex) 4 | boom w/ stick R3.9B |
| Max Vertical Wall Dig Depth | 5062.7 mm |
| Ground Clearance | 460.2 mm |
| Height To Top Of Cab | 2950.5 mm |
| Width To Outside Of Tracks | 2801.1 mm |
| Length Of Track On Ground | 3261.4 mm |
| Tail Swing Radius | 2770.6 mm |
| Track Gauge | 2200.7 mm |
| Shoe Size | 600.2 mm |
| Drawbar Pull | 19986.4 kg |
| Max Travel Speed | 5.5 km/h |
| Engine Make | 2236 |
| Engine Model | ATAAC engine 2066 |
| Gross Power | 102.9 kw |
| Operating Weight | 21760 kg |
| Reference Bucket Capacity | 0.8 m3 |
