| Kondisi | Used |
|---|---|
| Lokasi | KALIMANTAN TIMUR |
For Articulated Dump Truck :
- Brand Volvo
- Model A60H
- As Is Condition & Running
- Year Manufacturing 2019
- Location Kalimantan Jobsite - Indonesia
- Available 3 Units
- Price ex Works US$ 195,000 per Unit
Rp. 195
Technical Specifications
| Overall Length | 12225.5 mm |
|---|---|
| Overall Width | 6312.4 mm |
| Overall Height | 3852.7 mm |
| Wheelbase | 3294.9 mm |
| Ground Clearance | 679.7 mm |
| Dump Height | 7961.4 mm |
| Dump Ground Clearance | 1030.2 mm |
| Dump Angle | 70 degrees |
| Capacity - Heaped | 33.6 m3 |
| Lower Time | 10 sec |
| Capacity - Struck | 25.8 m3 |
| Battery Capacity | 2x225 |
| Alternator | 2.264/80 |
| Voltage | 24 V |
| Starter Motor | 9 |
| Battery | 2x12 |
| Plate Thickness-Front | 10.2 mm |
| Plate Thickness-Sides | 15.2 mm |
| Plate Thickness-Bottom | 17.8 mm |
| Plate Thickness-Chute | 17.8 mm |
| Horsepower | Gross-Sae J1995 630 |
| Horsepower Per Sae J1349 Net | 466.8 kw |
| Max Engine Speed | 1800 rpm |
| Engine Make | Volvo |
| Engine Model | D16J |
| Gross Torque | 2960 Nm |
| Net Torque | 2942.1 Nm |
| Displacement | 16.1 L |
| Torque Converter | 1.85:1 |
| Dropbox | IL3 ATC |
| Axles | AHW80 |
| Transmission | 6630 ORS |
| Fuel Tank | 750.3 L |
| Hydraulic Tank | 198.4 L |
| Cooling System | 75.3 L |
| Def Tank | 60.2 L |
| Transmission | 58.3 L |
| Crankcase | 55.3 L |
| Brake Cooling System | 131.4 L |
| Dropbox | 12.1 L |
| Transmission Type | Auto |
| Number Of Forward Gears | 6 |
| Number Of Reverse Gears | 2 |
| Max Speed | 55 km/h |
| Total Operating Weight | 98750 kg |
| Maximum System Pressure | 27999.6 kPa |
