| Kondisi | Used |
|---|---|
| Lokasi | BANTEN |
Dijual atas Unit Motor Grader :
- Merek Komatsu
- Model GD705A-4
- Ex Import / Built Up
- Masuk Indonesia tahun 2019
- Dilengkapi Ripper
- Memakai Cabin
- Unit siap kerja
- Harga Rp. 2,45 Milyar
Rp. 2,45 M
Technical Specifications
| Overall Length | 9272 mm |
|---|---|
| Width Over Tires | 2801.1 mm |
| Wheelbase | 6452.6 mm |
| Rear Ground Clearance | 411.5 mm |
| Tandem Axle Wheelbase | 1731.3 mm |
| Blade Base | 2901.7 mm |
| Height To Top Of Isomount Cab | 3560.1 mm |
| Number Of Cylinders | 6 |
| Engine Make | 2238 |
| Engine Model | S6D125 |
| Power Measured @ | 2000 rpm |
| Max Power | 149.1 kw |
| Net Power Gears 7-8 | 149.1 kw |
| Displacement | 11.1 L |
| Std Operation Weight - Total | 17620 kg |
| Fuel Capacity | 400.1 L |
| Tire Size | 16.00-24-12PR |
| Articulation Angle | 26 degrees |
| Turning Radius | 7528.6 mm |
| Number Of Gears - Forward | 8 |
| Max Speed - Forward | 43.1 km/h |
| Max Speed - Reverse | 46 km/h |
| Ground Clearance | 426.7 mm |
| Moldboard Width | 4328.2 mm |
| Moldboard Height | 701 mm |
