| Kondisi | Used |
|---|---|
| Lokasi | DKI JAKARTA |
Dijual atas Excavator :
- Merek Caterpillar
- Model D3K XL
- Ex Import / Built Up
- Masuk Indonesia tahun 2019
- Memakai Cabin
- Singgle Grouser Shoe
- Dapat Tilt di Blade
- Harga Rp. 485 Juta
Rp. 485 Jt
Technical Specifications
| Length W/ Blade | 4267.2 mm |
|---|---|
| Width Over Tracks | 1898.9 mm |
| Height To Top Of Cab | 2715.8 mm |
| Length Of Track On Ground | 2109.2 mm |
| Ground Clearance | 329.2 mm |
| Length W/Blade | 3273.6 mm |
| Track Gauge | 1496.6 mm |
| Standard Shoe Size | 406.4 mm |
| Number Of Shoes Per Side | 41 |
| Ground Pressure | 44.8 kPa |
| Ground Contact Area | 1.7 m2 |
| Number Of Track Rollers Per Side | 6 |
| Number Of Cylinders | 4 |
| Engine Make | 2236 |
| Engine Model | C4.4 ACERT |
| Gross Power | 60.4 kw |
| Net Power | 55.2 kw |
| Displacement | 4.4 L |
| Operating Weight | 7795 kg |
| Fuel Capacity | 194.9 L |
| Cooling System Fluid Capacity | 22.7 L |
| Engine Oil Capacity | 11.4 L |
| Hydraulic Fluid Capacity | 59.4 L |
| Final Drives Fluid Capacity | 9.8 L |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 120 amps |
| Transmission Type | Hydrostatic |
| Max Speed - Forward | 9 km/h |
| Max Speed - Reverse | 10 km/h |
| Relief Valve Pressure | 20601.5 kPa |
| Pump Flow Capacity | 73.4 L/min |
| Width | 2651.8 mm |
| Height | 909.3 mm |
| Capacity | 1.5 m3 |
| Blade Angle (Both Directions) | 25 degrees |
| Cutting Depth | 571.5 mm |
